30GTS SPECS↓

GVWR 41,600 lbs

Capacity (Distributed) 32,140 lbs

Base Trailer Weight 9,460 lbs

Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter rails

Crossmembers 4" x 2” Tubular Crossmembers on 16” Centers

Hitch 2 - 5/16” Gooseneck Coupler, 30,000 lb Capacity

Landing Gear 12,000 lb Capacity with Drop Foot

Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches

Deck Latch Over-Center Slider Shaft Latch with Tension Adjuster and Safety Pin

Cushion Cylinder 4" x 16" with Metered Flow to Cushion Loading and Unloading

Load Securement 18 Each (9 per side) 2-way Chain Slot/Stake Pocket System | 14 Each (7 per side) 1" Diameter D-Rings

Tool Compartment In Upper Gooseneck with Lockable Lid

Axles Qty 2 – 16,000 lb Capacity

Hubs Oil Bath Type, 8 on 275mm Bolt Circle with M22 Lug Nuts

Brakes 12-1/4" x 5" Electric Brakes both Axles with 12 Volt Sealed Breakaway System

Suspension 3-Point Spring with Axle Alignment Capability

Wheels 17.5" x 6.75" 8 on 275mm Bolt Pattern

Tires ST215/75R 17.5 Radial Load Range H

Finished Preparation Sandblast

Finish Coating Powder Coat with Zinc Primer

Electrical Philips Sealed Harness System with Rubber Isolated LED Lighting

Decking 2” Rough Surface No.1 Grade Fir with Fasteners at all Crossmembers

Decking Width 102”
